Gearless Lift Manufacturers

Capacity

03 to 20 passengers

Application

Bungalows, Commercial Offices, Industries, High Rise Buildings, Hotels, Monuments.

Speed

0.32 to 1.5 mt/ps

Sigma Gearless Private Limited, as the name itself suggests, having a strong recommendation for gearless elevators. In the era of Urbanization, the growing infrastructure it is our social responsibility to meet sustainable development.

Increasing impetus to meet the deficiency of natural resources, curbing pollution alongside leading intellectual engineering, Sigma adopted gearless technology as a dominant elevator system.

Gearless Elevators works on the core principle of energy-saving, regenerative system, efficient and stable operation. Geared machine consists of gearbox and motor, thus in the absence of gearbox oiling orgreasing is not required, which renders into lower maintenance hassles.

Gearless Motors also known as permanent magnet synchronous motored gearless machines. They have unapproachable superiority to the traction motor and save roughly 33% of energy consumption realtime adjustment to motor current, high torque featuring excellent reliability and durability, with compact design and lightweight elevator solutions.

COMPETENT SPACE

STEADY OPERATION

ENERGY EFFICIENCY

DYNAMIC CONTROL

AESTHETIC DESIGN

Features at a glance

  • Green and energy regeneration technology.
  • Noise-free motion and vibration absorption.
  • High-tech safety and security features.
  • Simple and reliable installation process.
  • Minimize Construction Cost and Time.
  • Architectural designing flexibility.
  • Minimal headroom requirement.
  • Low and affordable maintenance.

Technical Specification

Auto Plan

LOAD SHAFT SIZE CAR SIZE ENTRANCE
WIDTH DEPTH WIDTH DEPTH
PERSON KGS A B C D E
5 340 1900 1300 1100 700 700
6 408 1900 1700 1100 1000 700
8 544 1900 1900 1300 1100 800
10 680 1900 2100 1300 1350 800
13 884 2500 1900 2000 1100 900
16 1088 2500 2100 2000 1300 1000
20 1360 2500 2400 2000 1500 1000
26 1768 2300 2900 2500 1500 1200

Manual Plan

LOAD SHAFT SIZE CAR SIZE ENTRANCE
WIDTH DEPTH WIDTH DEPTH
PERSON KGS A B C D E
5 340 1600 1300 1100 850 700
6 408 1670 1370 1100 1000 700
8 544 1800 1600 1300 1100 800
10 680 1850 1800 1300 1300 800
13 884 2500 1600 2000 1100 900
16 1088 2500 1800 2000 1300 1000
20 1360 2500 2050 2000 1550 1000

All dimensions are in mm. This is general data, it may be changed without notice. All hoist way walls should be minimum 230 mm brick or 150 mm rcc. Pit Depth 1 600 mm and Overhead Height 5000 mm upto 1 .5 mps. Pit Depth 2600 mm and Overhead Height 6700 mm upto 2.5 mps
